Shape K – Synchronous Pulley Wheel for 6mm S3M Belt

Q & A
More Products

Item Name: Shape K – Synchronous Pulley Wheel for 6mm S3M Belt Material: Aluminum Alloy Shape Type: K Timing Belt Fit: S3M, 6 mm Width Tapping Lock: Yes PCs in Item: 1 PC Manufacturer: N/A, Made in China Specification Model Shaft (Ø) d (mm) ØD (mm) Teeth Width (mm) H Overall Width L (mm) 20 Teeth-5 5 22 7 10 18.46 20 Teeth-6.35 6.35 22 7 10 18.46 20 Teeth-8 8 22 7 10 18.46 22 Teeth-5 5 25 7 10 18.6 22 Teeth-6.35 6.35 25 7 10 18.6 22 Teeth-8 8 25 7 10 18.6
