Description 4 Inch Row Crop Sweep for Opening Foot on Cole 12 MX MultiFlex 3 Pt. Planter and Other Similar Footpieces The 4 Inch Row Crop Sweep has a Low Crown and Flanged Neck for Flat Running, High Speed Cultivation. Constant Width Assures Maximum Life. 1/4″ Thick. Stem Angle is 55 degrees 7/16″ bolt size with 2″ hole spacing. Please Note: This does not attach to an S-tine – only to footpieces With a smooth beveled point these Row Crop Sweeps are heavier and thicker than the competition. The #76A304 4 Inch Row Crop Sweep fits on the B46-674 Opening Foot for the Cole 12MX Attach this 4 Inch Row Crop Sweep to the Opening Foot as it is used to top beds so that seeds are planted in moist soil, and levels seed bed for more uniform seed depth. The Row Crop Sweep and Opening Foot Cannot be used with B46-676 Gauge Wheel. Recommended that depth slide be removed when using the B46-674 Opening Foot with a Row Crop Sweep. Pictured above is the B46-674 Opening Foot with a 4 Inch Row Crop Sweep attached (The 4 Inch Row Crop Sweep is not included with the B46-674 Opening Foot). Different sizes of Row Crop Sweeps can be attached. See Also the #76A306 6″ Row Crop Sweep And the #76A308 8″ Row Crop Sweep The #76A304 4 Inch Row Crop Sweep can be attached to a number of Footpieces such as our Flat Shank with Footpiece
